CK50D/CK60D solar charge controller pwm controller

Cate：

CK series

This series is a new generation of multi-functional and intelligent solar charge and discharge controllers. The innovative structured design makes the installation and use of the controller safer and more reliable. The optimized charge and discharge management greatly improves the service life of the battery. At the same time, the large LCD display screen contains richer display content, the patterns are beautiful and easy to understand, and the streamlined display management maximizes the display of the system's working status and corresponding parameters. A variety of control parameters can be set to meet a variety of different application requirements.

零售价

0.0

元

市场价

0.0

元

浏览量:

1000

产品编号

数量

库存:

Cate

Back



Honor

CK50D/CK60D solar charge controller pwm controller

[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[产品参数, 参数]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]

Product Description

CK SERIES
INTELLIGENT SOLAR CHARGE CONTROLLER

CK series solar charge controller is an extension of a classic controller.The appearance of this controller is simple and clear,little red button design makes it easy to use.The product inheriting and optimizing the classic circuit design, added USB 5V output and DC 12V output terminal,enable controller can charge cellphones and other electronic devices. Considerate solar panel,battery and load protection making this product more outstanding.

Key Features

PWM charging
Multistage charging technology(Bulk,Absorption,Float,Equalized)
Voltage regulation
Automatic detection of voltage
Automatic load reconnection
Automatic temperature compensation
Various controlling modes for load(light control,time&light control,normal mode)
Adaptable to Sealed, Gel, Flooded and other customized
battery type
Preset parameters for charging and discharging (Special
parameters can be customized)
Optional communication function

Electronic Protections

Over charge protection
Over discharge protection
Over temperature and over load protection
Automatic electronic fuse
Short circuit protection of load and PV
Input over voltage protection
Reverse current protection at night
Reverse connection protection of PV, load, and battery

Displays

Vivid LCD graphic symbols
---presents working status and related parameters explicitly
